In this article, we will talk about how to install NFS Server in Centos 9 or Rocky Linux 9. NFS stands for Network File System which is an Internet Standard Protocol and allows to share files in between various systems residing on the Local Area Network. In a typical setup an NFS Server is setup and shares (directories) are exported, systems running Linux or Windows can map these shared directories.

Installing NFS Server

In order to install NFS server in Centos 9 or Rocky Linux, we use dnf package manager to install the required packages.

[root@server1 ~]# dnf install nfs-utils

you can get more information about what is provided in the nfs-utils package by issuing following command

[root@server1 ~]# dnf info nfs-utils
...
Installed Packages
Name         : nfs-utils
Epoch        : 1
Version      : 2.3.3
Release      : 51.el8
Architecture : x86_64
Size         : 1.5 M
Source       : nfs-utils-2.3.3-51.el8.src.rpm
Repository   : @System
From repo    : baseos
Summary      : NFS utilities and supporting clients and daemons for the kernel NFS server
URL          : http://linux-nfs.org/
License      : MIT and GPLv2 and GPLv2+ and BSD
Description  : The nfs-utils package provides various utilities for use with NFS
             : clients and servers.

Exporting the Share

The file /etc/exports contains the information and control parameters about the shares which will be advertised to the client machines.

  • Create a directory in the local filesystem of your Linux machine.
[root@server1 ~]# mkdir /nfs_share
  • Open /etc/exports file in your favourite editor such as vi or nano.
[root@server1 ~]# vi /etc/exports

Insert the following line. Save and Exit the file.

/nfs_share    10.0.0.0/24(rw,sync,root_squash,no_subtree_check)

Let’s understand the configuration.

  • /nfs_share is the local directory (on NFS Server) which will be advertised as a share to other systems
  • 10.0.0.0/24 defines the network which is allowed to access this share. You can restrict the access to a share to
1. Single Host (10.0.0.11)2. Entire Network (10.0.0.0/24)
3. Wildcard Machine names (*.itinfotech.ca)4. Host Groups
  • Share Options
rwAllow both read and write requests on this NFS volume.
syncmakes sure that changes have been saved to persistent store (disk). Opposite is async option, which means changes made to the files are written in memory before they are saved to persistent media.
root_squashthis option makes sure that requests coming from uid 0 (root user) are mapped to anonymous uid such as nobody. In plain words, if the root user on client machine modifies any file, the ownership (user and group) will be shown as nobody:nobody instead of root:root
no_subtree_checksubtree checking is a process which makes sure that if a subdirectory of the filesystem (folder within a folder) is exported, but the main filesystem (parent directory) is not, server must check the accessed files are in appropriate file system and also in the exported tree. no_subtree_check disables this checking

There are various other options available. For the complete list of options, please refer to the man page of exportfs or use this link

Start the nfs-server service or if the server was already running, export the shares.

[root@server1 ~]# systemctl start nfs-server.service

or

[root@server1 ~]# exportfs -av
exporting 10.0.0.0/24:/nfs_share

Client Setup

In the client Linux machine, install the nfs-utils package.

[root@server1 ~]# dnf install nfs-utils

Mounting the NFS Share temporarily

[root@client ~]# mount -t nfs <server_ip>:/nfs_share /share -vvv

Above command will mount the nfs share named nfs_share on client’s directory /share

Mounting the NFS Share permanently

open the /etc/fstab file in your favourite editor and insert the following line

<server_ip>:/nfs_share  /share      nfs     defaults        0 0

Don’t forget to replace server_ip with your NFS Server’s IP Address.

Save and exit the file. Issue the mount command.

[root@client ~]# mount -a

Verify the Share Exist in client machine

If the mount command was successful, you can verify that share is available to use as shown below

[root@client ~]# df -hT
Filesystem                Type      Size  Used Avail Use% Mounted on
10.0.0.x:/nfs_share    nfs4       37G  4.8G   32G  1% /share
tmpfs                     tmpfs     374M     0  374M   0% /run/user/0
[root@client share]# touch testfile
[root@client share]# ll
total 1
-rw-r--r-- 1 nobody nobody  0 Oct  8 00:40 testfile

Voilla! You have successfully created your own NFS Server. If you have any question or you are stuck feel free to comment in the comment section below.
